Key parameters

• Ready for in line/off line solution
• 4MPx, 8MPx or 12MPx camera
• Available with 10,15 and 20 µ telecentric lens
• Inspection speed 13.3-91.2 cm²/sec depending on lens resolution
• 2-4 moiré 3D shadow free projections
• Available in M, L, XL, 2XL size and Dual Lane
• Maximum PCB dimension up to 1500x690mm (2XL)

Key benefits

• Zero-defect through AI-Powered Koh Young Process Optimizer (KPO) Printer
• Best-in-class Measurement Accuracy and Inspection Reliability
• 4 moiré projection provides highest accuracy independently on PCB rotation
• Real-time Warp Compensation
• KSMART Solutions: True 3D Measurement-based Process Control System and connection with other SPI/ AOI Koh Young machine
• Foreign materials inspection (FMI) over whole surface of PCB
• Automated Solder Paste Dispensing: Auto-Rework (optional)

FAQ:

1. What is the accuracy of SPI?

• SPI height accuracy is 1µ and the system is ready for testing of pads for SMD 01005 components.

2. Why choose SPI from Koh Young?

• Koh Young delivers accurate and parameter 3D measurement and control of paste application, early detection and prevention of faulty printing, robust statistical process control, production optimization and lower rework costs.

3. What is the impact of SPI to FPY?

• SPI can increase FPY by up to 20%.
